Filters

Thread

Threaded connectors from MedNet create secure, leak-free connections in medical devices, laboratory setups and OEM assemblies where luer fittings are not suitable. Available in UNF, metric and custom thread standards, each connector provides precise dimensional tolerances and robust sealing under pressure. Use our threaded connectors to integrate sensors, filters and accessories into critical fluid paths while ensuring long-term mechanical and fluidic reliability.

Straight, Luer Male - Rotating Adaptor to UNF Male 1/4"-28, PP/PA, With Bottom Sealing Thread

Straight, Luer Male - Rotating Adaptor to UNF Male 1/4"-28, PP/PA, With Bottom Sealing Thread

ABSML-6005-1

With Bottom Sealing Thread

Details
Straight, Luer Male - Lock to Tapered Male 10-32, PA (Polyamide) White

Straight, Luer Male - Lock to Tapered Male 10-32, PA (Polyamide) White

XMTLL-1

Details
Straight, Luer Male - Lock to NPT 1/4"-18, PA (Polyamide) White

Straight, Luer Male - Lock to NPT 1/4"-18, PA (Polyamide) White

14MTLL-1

Details
Straight, Luer Male - Lock to NPT 1/8"-27, PA (Polyamide) White

Straight, Luer Male - Lock to NPT 1/8"-27, PA (Polyamide) White

18MTLL-1

Details
Straight, Luer Male - Lock to UNF Male 1/4"-28, PA (Polyamide) White

Straight, Luer Male - Lock to UNF Male 1/4"-28, PA (Polyamide) White

SMTLL-1

Details
Unvented, UNF, PA (Polyamide), White

Unvented, UNF, PA (Polyamide), White

SP-1

Details
Straight, Luer Male - Rotating Adaptor to Tapered Male 10-32, PA (Polyamide) White, Can be used with separate rotating lock ring (MLLR)

Straight, Luer Male - Rotating Adaptor to Tapered Male 10-32, PA (Polyamide) White, Can be used with separate rotating lock ring (MLLR)

XMTL-1

Can be used with separate rotating lock ring (MLLR)

Details
Straight, NPT Male 1/16"-27 to 200 Series Barb 3,2mm (1/8") ID, Kynar PVDF Natural

Straight, NPT Male 1/16"-27 to 200 Series Barb 3,2mm (1/8") ID, Kynar PVDF Natural

16230-J2A

Details
Straight, NPT Male 1/16"-27 to 200 Series Barb 4,8mm (3/16") ID, PA (Polyamide) Black

Straight, NPT Male 1/16"-27 to 200 Series Barb 4,8mm (3/16") ID, PA (Polyamide) Black

16250-2

Details
Straight Reducer, NPT Male 1/8"-27 to UNF Female 1/4"-28, PP (Polypropylene) - Animal Free Natural

Straight Reducer, NPT Male 1/8"-27 to UNF Female 1/4"-28, PP (Polypropylene) - Animal Free Natural

1802-6005

Details
Straight, NPT Male 1/8"-27 to Classic Series Barb 2,4mm (3/32") ID, PA (Polyamide) Black

Straight, NPT Male 1/8"-27 to Classic Series Barb 2,4mm (3/32") ID, PA (Polyamide) Black

1820-2

Details
Straight, NPT Male 1/8"-27 to 200 Series Barb 1,6mm (1/16") ID, PA (Polyamide) White

Straight, NPT Male 1/8"-27 to 200 Series Barb 1,6mm (1/16") ID, PA (Polyamide) White

18210-1

Details
Straight, NPT Male 1/8"-27 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

Straight, NPT Male 1/8"-27 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

18230-1

Details
Straight, NPT Male 1/8"-27 to 200 Series Barb 4,0mm (5/32") ID, PP (Polypropylene) - Animal Free Natural

Straight, NPT Male 1/8"-27 to 200 Series Barb 4,0mm (5/32") ID, PP (Polypropylene) - Animal Free Natural

18240-6005

Details
Straight, NPT Male 1/8"-27 to 400 Series Barb 4,3mm (.170") ID, PA (Polyamide) White

Straight, NPT Male 1/8"-27 to 400 Series Barb 4,3mm (.170") ID, PA (Polyamide) White

18445-1

Details
Straight, NPT Male 1/8"-27 to Classic Series Barb 4,8mm (3/16") ID, PA (Polyamide) White

Straight, NPT Male 1/8"-27 to Classic Series Barb 4,8mm (3/16") ID, PA (Polyamide) White

1850-1

Details
Straight, NPT Male 1/8"-27 to Classic Series Barb 6,4mm (1/4") ID, PA (Polyamide) White

Straight, NPT Male 1/8"-27 to Classic Series Barb 6,4mm (1/4") ID, PA (Polyamide) White

1860-1

Details
Elbow, NPT Male 1/8"-27 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

Elbow, NPT Male 1/8"-27 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

18L230-1

Details
Elbow, NPT Male 1/8"-27 to 200 Series Barb 4,8mm (3/16") ID, PA (Polyamide) White

Elbow, NPT Male 1/8"-27 to 200 Series Barb 4,8mm (3/16") ID, PA (Polyamide) White

18L250-1

Details
Elbow, NPT Male 1/8"-27 to 200 Series Barb 6,4mm (1/4") ID, PA (Polyamide) White

Elbow, NPT Male 1/8"-27 to 200 Series Barb 6,4mm (1/4") ID, PA (Polyamide) White

18L260-1

Details
T, NPT Male 1/8"-27 to 200 Series Barb 6,4mm (1/4") ID, PA (Polyamide) White

T, NPT Male 1/8"-27 to 200 Series Barb 6,4mm (1/4") ID, PA (Polyamide) White

18T260-1

Details
Straight, UNF Male - Rotating Adaptor 1/4"-28 to 500 Series Barb 1,6mm (1/16") ID, PP/PA

Straight, UNF Male - Rotating Adaptor 1/4"-28 to 500 Series Barb 1,6mm (1/16") ID, PP/PA

ABR004-6005-1

Details
Straight, UNF Male - Rotating Adaptor 1/4"-28 to 500 Series Barb 2,4mm (3/32") ID, PP/PA

Straight, UNF Male - Rotating Adaptor 1/4"-28 to 500 Series Barb 2,4mm (3/32") ID, PP/PA

ABR007-6005-1

Details
Straight, UNF Male - Rotating Adaptor 1/4"-28 to 500 Series Barb 3,2mm (1/8") ID, PP/PA

Straight, UNF Male - Rotating Adaptor 1/4"-28 to 500 Series Barb 3,2mm (1/8") ID, PP/PA

ABR013-6005-1

Details
Straight, UNF Female 5/16"-24 to 500 Series Barb 4,0mm (5/32") ID, PA (Polyamide) White / Black

Straight, UNF Female 5/16"-24 to 500 Series Barb 4,0mm (5/32") ID, PA (Polyamide) White / Black

BPA025-001

Details
Straight, UNF Female 5/16"-24 to 500 Series Barb 4,8mm (3/16") ID, PA (Polyamide)

Straight, UNF Female 5/16"-24 to 500 Series Barb 4,8mm (3/16") ID, PA (Polyamide)

BPA035-001

Details
Straight, UNF Male 5/16"-24 to 200 Series Barb 4,0mm (5/32") ID, Acetal Natural

Straight, UNF Male 5/16"-24 to 200 Series Barb 4,0mm (5/32") ID, Acetal Natural

BPC240-10

Details
Straight, UNF Male 10-32 to 200 Series Barb 1,6mm (1/16") ID, PA (Polyamide) White

Straight, UNF Male 10-32 to 200 Series Barb 1,6mm (1/16") ID, PA (Polyamide) White

K210-1

Details
Straight, UNF Male 10-32 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

Straight, UNF Male 10-32 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

K230-1

Details
Straight, UNF Male 10-32 to 200 Series Barb 4,0mm (5/32") ID, PP (Polypropylene) - Animal Free Natural

Straight, UNF Male 10-32 to 200 Series Barb 4,0mm (5/32") ID, PP (Polypropylene) - Animal Free Natural

K240-6005

Details
Straight, UNF Male 10-32 to 400 Series Barb 2,4mm (3/32") ID, PP (Polypropylene) - Animal Free Natural

Straight, UNF Male 10-32 to 400 Series Barb 2,4mm (3/32") ID, PP (Polypropylene) - Animal Free Natural

K420-6005

Details
Elbow, UNF Male 10-32 to 200 Series Barb 1,6mm (1/16") ID, PA (Polyamide) White

Elbow, UNF Male 10-32 to 200 Series Barb 1,6mm (1/16") ID, PA (Polyamide) White

KL210-1

Details
Elbow, UNF Male 10-32 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

Elbow, UNF Male 10-32 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

KL230-1

Details
T, UNF Male 10-32 to 400 Series Barb 1,6mm (1/16") ID, PA (Polyamide) White

T, UNF Male 10-32 to 400 Series Barb 1,6mm (1/16") ID, PA (Polyamide) White

KT410-1

Details
Straight, Metric Male M5 x 0,8 to 200 Series Barb 1,6mm (1/16") ID, PA (Polyamide) White

Straight, Metric Male M5 x 0,8 to 200 Series Barb 1,6mm (1/16") ID, PA (Polyamide) White

M5210-1

Details
Straight, Metric Male M5 x 0,8 to 200 Series Barb 2,4mm (3/32") ID, PA (Polyamide) White

Straight, Metric Male M5 x 0,8 to 200 Series Barb 2,4mm (3/32") ID, PA (Polyamide) White

M5220-1

Details
Straight, Metric Male M5 x 0,8 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

Straight, Metric Male M5 x 0,8 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

M5230-1

Details
Straight, Metric Male M6 x 1 to 200 Series Barb 1,6mm (1/16") ID, PP (Polypropylene) - Animal Free Natural

Straight, Metric Male M6 x 1 to 200 Series Barb 1,6mm (1/16") ID, PP (Polypropylene) - Animal Free Natural

M6210-6005

Details
Straight, Metric Male M6 x 1 to 200 Series Barb 2,4mm (3/32") ID, PP (Polypropylene) - Animal Free Natural

Straight, Metric Male M6 x 1 to 200 Series Barb 2,4mm (3/32") ID, PP (Polypropylene) - Animal Free Natural

M6220-6005

Details
Straight, Metric Male M6 x 1 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

Straight, Metric Male M6 x 1 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

M6230-1

Details
Straight, Metric Male M6 x 1 to 200 Series Barb 4,8mm (3/16") ID, PA (Polyamide) Black

Straight, Metric Male M6 x 1 to 200 Series Barb 4,8mm (3/16") ID, PA (Polyamide) Black

M6250-2

Details
Straight, UNF Male 1/4"-28 to 200 Series Barb 2,4mm (3/32") ID, PP (Polypropylene) - Animal Free Natural

Straight, UNF Male 1/4"-28 to 200 Series Barb 2,4mm (3/32") ID, PP (Polypropylene) - Animal Free Natural

S220-6005

Details
Straight, UNF Male 1/4"-28 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

Straight, UNF Male 1/4"-28 to 200 Series Barb 3,2mm (1/8") ID, PA (Polyamide) White

S230-1

Details
Straight, UNF Male 1/4"-28 to 200 Series Barb 4,0mm (5/32") ID, PP (Polypropylene) - Animal Free Natural

Straight, UNF Male 1/4"-28 to 200 Series Barb 4,0mm (5/32") ID, PP (Polypropylene) - Animal Free Natural

S240-6005

Details
Straight, UNF Male 1/4"-28 to 200 Series Barb 4,8mm (3/16") ID, Kynar PVDF Natural

Straight, UNF Male 1/4"-28 to 200 Series Barb 4,8mm (3/16") ID, Kynar PVDF Natural

S250-J2A

Details
Straight, UNF Male 1/4"-28 to 400 Series Barb 1,6mm (1/16") ID, PP (Polypropylene) - Animal Free Natural

Straight, UNF Male 1/4"-28 to 400 Series Barb 1,6mm (1/16") ID, PP (Polypropylene) - Animal Free Natural

S410-6005

Details
Elbow, Tapered Male 10-32 to 200 Series Barb 2,4mm (3/32") ID, PA (Polyamide) Black

Elbow, Tapered Male 10-32 to 200 Series Barb 2,4mm (3/32") ID, PA (Polyamide) Black

XL220-2

Details
No image available

Straight, Metric Male M5 x 0,8 to 200 Series Barb 4,0mm (5/32") ID, Kynar PVDF Natural

M5230-J2A

Details
No image available

Straight, UNF Male 10-32 to UNF Male 10-32, PA (Polyamide) Black

KN-2

Details
